tp-link - Modem Routeur VDSL/ADSL WiFi N 300 Mbps - TD-W9970

49.00€

Le prix comprend la TVA 20% (20%) 8.17€

5 disponible

Quantité :

Détails du produit

CARACTERISTIQUES MATERIELLES

Interface	4 10/100Mbps RJ45 Ports 1 RJ11 Port 1 USB 2.0 Port
Ports	1× 10/100 Mbps LAN/WAN Port, 3× 10/100 Mbps LAN ports, 1× RJ11 port, 1× USB 2.0 Port
Bouton	1 Power On/Off Button 1 WPS/RESET Button 1 Wi-Fi On/Off Switch
Alimentation externe	12VDC/1A
Standards IEEE	IEEE 802.3, 802.3u
Standards VDSL2	ITU-T G.993.2 ITU-T G.993.5 (G.vector) ITU-T G.998.4 (G.INP）
Standards ADSL	Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1(G.DMT) ITU-T G.994.1 (G.hs) ITU-T G.995.1
Standards ADSL2	ITU-T G.992.3 (G.dmt.bis)
Standards ADSL2+	ITU-T G.992.5
Dimensions (LxPxH)	195×130×36mm
Antenne	2 × 4dBi Fixed Omni-Directional Antennas
Type d'antenne	Omni directional, Fixed
Gain de l'antenne	2 x 5dBi

CARACTERISTIQUES WIFI

Standards WiFi	IEEE 802.11b, 802.11g, 802.11n
Fréquence	2.400-2.4835GHz
Débit du signal	300 Mbps at 2.4 GHz
Puissance de transmission	<20dBm(EIRP)
Fonctions WiFi	Enable/Disable Wireless Radio, WMM, Wireless Statistics
Sécurité WiFi	Support 64/128 bit WEP, WPA /WPA2, WPA-PSK/WPA2-PSK Wireless MAC Filtering

CARACTERISTIQUES LOGICIELLES

Qualité de Service QoS	WMM, Bandwidth Control (IP QoS)
Sécurité	NAT Firewall, SPI Firewall, MAC / IP / URL Filtering
IPv6	IPv6 and IPv4 dual stack Supported IPv6 Tunnels: DS-Lite, 6RD, 6 to 4 Supported IPv6 Connection Type: PPPoEv6, DHCPv6, Static IPv6
Modes opératoires	DSL Modem Router, 3G/4G Router, Wireless Router
Administration	Web Based Configuration(HTTP), Remote management, Telnet management, Command Line Interface, SSL for TR-069, SNMP V1/V2C, Web Based Firmware Upgrade, CWMP(TR-069), Diagnostic Tools
DHCP	Server, Client, DHCP Client List, Address Reservation, DHCP Relay
Redirection de port	Virtual server, Port Triggering, UPnP, DMZ, Manage Control
DNS dynamique	DynDns, NO-IP
VPN Pass-Through (ne bloque pas un lien VPN)	PPTP, L2TP, IPSec Pass-through
Protocoles	Supports IPv4 and IPv6
Protocoles ATM/PPP	ATM Forum UNI3.1/4.0 PPP over ATM (RFC 2364) PPP over Ethernet (RFC2516) IPoA (RFC1577/2225) PVC - Up to 8 PVCs
Caractéristiques avancées	Ethernet WAN (EWAN) Guest Network, Wireless Schedule Parent Control Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt; Dynamic Host Configuration Protocol (DHCP), DHCP relay; Network Address Translation (NAT); PVC/Ethernet Port Grouping Static Routing, RIP v1/v2 (optional); DNS Relay, DDNS, IGMP snooping V1/2 IGMP Multicast, UPnP
Partage USB	Storage Sharing FTP Server Media Server Print Server
Réseau invité	2.4 GHz Guest Network
IGMP	IGMP snooping V1/V2/V3 IGMP Multicast
VPN IPsec	10 IPSec VPN Tunnels LAN-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, AES128, AES192, AES256 Encryption Algorithm MD5, SHA1 Authentication Algorithm Manual, IKE Key Management Mode Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS)

AUTRES

Certification	CE, RoHS
Contenu de l'emballage	TD-W9970 External Splitter RJ-11 Telephone Line RJ-45 Ethernet Cable Quick Installation Guide Resource CD Power Adapter
Système requis	Windows 10/8.1/8/7/Vista/XP or Mac OS or Linux-based operating system
Environnement	Operating Temperature: 0~40°C Storage Temperature: -40~70°C Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
