ELC-AQF240-SQA-W | ||
Intel® compatible Sockets | LGA 1200, 115x, 1366, 2011(-3) Square ILM, 2066 | |
AMD® compatible Sockets | FM1, FM2(+), AM2(+), AM3(+), AM4, Ryzen 3000 XT | |
Cold Plate Material | Nickel plated copper | |
Weight without Fan | 600 g | |
Thickness including Fan | 53.7mm | |
Thermal Design Power (TDP) | 300W | 360W |
Thermal Grease | Dow Corning® TC-5121 2g | |
RGB Sync. Connector | 3 pin ARGB (5V/Data/-/GND) | |
RGB Sync. Compatibility | Asus, Asrock, MSI, Gigabyte (with adaptor), Razer Chroma (with Asrock and MSI mainboards) | |
Lighting Modes | Racing-Rainbow (Default), Breathing-Rainbow, Flash-Rainbow, Overlaying-Rainbow, Flow-Rainbow, Colors auto-run (8 colors), Ripple auto-run (8 colors), Overlaying-RED, Overlaying-GREEN, Overlaying-BLUE | |
Power Connector | SATA Power | |
Max. Current | 3A | |
Pump | ||
Bearing Type | Ceramic bearing | |
MTBF | 50,000h | |
Motor Speed | 3.100RPM | |
Rated Voltage Pump | 12V | |
Rated Current Pump | 0.7A | |
Rated Voltage RGB LED | 5V | |
Rated Current RGB LED | 0.42A | |
Pump Power Connector | 3 pin (GND/12V/Tacho) | |
Radiator | ||
Dimensions | 154 x 120 x 27 mm | 274 x 120 x 27 mm |
Material | Aluminium | |
Tubes | ||
Length | 400mm | |
Material | Rubber (Polyamide) | |
Fan | ||
Fan Model | SquA RGB | |
LED Type | WS2812B addressable RGB | |
Bearing Type | – | |
MTBF | 100,000h | |
Fan Dimensions | 120 x 120 x 26mm | |
Fan Speed | 500 – 2,000RPM | |
Rated Voltage Fans | 12V | |
Rated Current Fans | 0.38 A | 0.76 A (2x 0.38A) |
Rated Voltage RGB LEDs | 5V | |
Rated Current RGB LEDs | 0.68A | 1.36A (2x 0.68 A) |
Fan Power Connector | 4 pin PWM (GND/12V/Tacho/PWM) | |
Quantity | 1 | 2 |
Noise Level | 17 ~ 32.6 dBA | |
Air Flow | 39 ~ 79.8 CFM | |
Static Pressure | 0.67 ~ 3.6 mm-H2O | |
Included in the delivery | Liquid cooler, 12cm SquA RGB fans, universal mounting kit for Intel® and AMD® sockets, Dow-Corning® Thermal Grease (TC-5121), PWM fan Y-cable, molex adapter, RGB control box, RGB sync cable, SATA RGB controller power cable, RGB Gigabyte cable, 24-pin power adaptor, 100ml coolant, installation guide | Liquid cooler, 2x 12cm SquA RGB fans, universal mounting kit for Intel® and AMD® sockets, Dow-Corning® Thermal Grease (TC-5121), PWM fan Y-cable, molex adapter, RGB control box, RGB sync cable, SATA RGB controller power cable, RGB Gigabyte cable, 24-pin power adaptor, 100ml coolant, installation guide |
